6651A-J03 特別訂購直流電源供應器

電壓:6V 電流:60A 功率:500W

目前上市/現已支援

產品詳細介紹
  • Output Ratings

    • Output voltage: 6 V
    • Output current (40°C): 60 A
    • Maximum current (50°C/55°C): 54 A/5 1A

    Programming Accuracy at 25°C ±5°C

    • Voltage 0.06% + 5 mV
    • Current 0.15% + 75 mA

    Ripple & Noise from 20 Hz to 20 MHz

    • Voltage rms: 300 µV
    • Peak-to-Peak: 3 mV
    • Current rms: 30 mA

    Readback Accuracy at 25°C ±5°C (per

    • Voltage 0.07% + 6 mV
    • +Current 0.15% + 80 mA
    • -Current 0.35% + 150 mA
  • 庫存量:來電洽詢

    一般配置

    6651A DC power supply, 0-8 V, 0-50 A, 400 W. GPIB

    • 6651A-120 104-127VAC operation, 50/60Hz
    • R-51B-001-Z Return to Keysight Warranty - 3 years
  • 6651A-J03  產品型錄
