Infiniium S系列示波器(高解析度示波器)
DSOS054A 高解析度示波器:500 MHz,4 個類比通道
Keysight DSOS054A 高解析度示波器:500 MHz,4 個類比通道

  目前上市/現可支援

* [量測影片] 使用S系列示波器執行USB 2.0 Device眼圖及Inrush Current測試

庫存: 來電洽詢
主要特點

Keysight DSOS054A 高解析度示波器:500 MHz,4 個類比通道

推薦頻寬500MHz、四個類比通道的高解析示波器DSOS054A,頻寬最高可升級到8GHz,取樣率高達20GSa/S。

* Keysight DSOS054A主要技術規格:

- 500 MHz 頻寬(最高可升級到8GHz)
- 4 個類比通道 (可升級16個數位通道)
- 20 GSa/s 最大取樣率,每通道標配 50 Mpts 記憶體,可擷取更長的信號軌跡
- 8.1 位元系統有效位元(ENOB)和 10 位元類比數位轉換器(ADC),可實現絕佳的信號完整性
- 15 吋多點觸控電容式觸控螢幕大幅提昇易用性,標配的固態硬碟可加速開機並提高可靠度
- 有各式各樣的協定、相符性測試和分析軟體可供選擇


* 查看應用白皮書:評估示波器的訊號完整性keysight應用手冊
* [量測影片] 使用S系列示波器執行USB 2.0 Device眼圖及Inrush Current測試


* 查看最新款八通道示波器: keysight EXR系列
* 查看更高頻寬: MSOS804A 8GHz,4通道 (點我查看)
* 查看其他系列示波器:  InfiniiVision 6000 X 系列示波器
* 查看Keysight示波器總覽:Keysight示波器系列

如需更多資訊: 查閱技術規格書

頻寬 500 MHz(最高可升級為8GHz)
通道數 4 (可升級16個數位通道)
最大的記憶體深度

800 Mpts(2 通道),400 Mpts(4 通道)

最大的取樣率

20 GSa/s(2 通道),10 GSa/s(4 通道)

ADC 位元 10 位元
