Infiniium S系列示波器(高解析度示波器)
MSOS404A 高解析度示波器:4 GHz,4 個類比通道和 16 個數位通道
MSOS404A 高解析度示波器:4 GHz,4 個類比通道和 16 個數位通道

  目前上市/現可支援

* [量測影片] 使用S系列示波器執行USB 2.0 Device眼圖及Inrush Current測試

庫存: 來電洽詢
主要特點

Keysight MSOS404A 高解析度示波器:4 GHz,4 個類比通道和 16 個數位通道

推薦使用頻率4GHz,四個類比通道及16個數位通道的高解析度示波器MSOS404A,具備 20 GSa/s 最大取樣率,可提供更出色的信號完整性

* MSOS404A主要技術規格:

- 4 GHz 頻寬(可升級, 最高到8GHz)
- 4 個類比通道和 16 個數位通道
- 具備 20 GSa/s 最大取樣率,每通道標配 50 Mpts 記憶體,可擷取更長的信號軌跡
- 具備 7.2 位元的系統有效位元數和 10 位元類比數位轉換器,可提供更出色的信號完整性
- 配備支援多點觸控的 15 吋電容式觸控螢幕,以及可靠、可快速啟動的固態硬碟,可全面提昇易用性
- 備有各式各樣的協定、相符性和分析軟體,可增進您的測試效率
- [量測影片] 使用S系列示波器執行USB 2.0 Device眼圖及Inrush Current測試


* 查看應用白皮書:評估示波器的訊號完整性keysight應用手冊
* 查看更高頻寬: MSOS804A 8GHz,4通道 (點我查看)
* 查看其他系列示波器:  InfiniiVision 6000 X 系列示波器
* 查看Keysight示波器總覽:Keysight示波器系列

如需更多資訊: 查閱技術規格書

頻寬 4 GHz
通道數 4 + 16
最大的記憶體深度 800 Mpts (2 channels), 400 Mpts (4 channels)
最大的取樣率 20 GSa/s (2 channels), 10 GSa/s (4 channels)
ADC 位元 10 bits
