6654A-J12 特別訂購直流電源供應器

電壓:80V 電流:6A 功率:500W

目前上市/現已支援

產品詳細介紹
  • Output Ratings

    • Output voltage: 80 V
    • Output current (40°C): 6 A
    • Maximum current (50°C/55°C): 5.4 A/5.1 A

    Programming Accuracy at 25°C ±5°C

    • Voltage 0.06% + 35 mV
    • Current 0.15% + 7 mA

    Ripple & Noise from 20 Hz to 20 MHz

    • Voltage rms: 700 µV
    • Peak-to-Peak: 7 mV
    • Current rms: 3 mA

    Readback Accuracy at 25°C ±5°C (per

    • Voltage 0.07% + 58 mV
    • +Current 0.15% + 6 mA
    • -Current 0.35% + 16 mA
  • 庫存量:來電洽詢

  • 6654A-J12  產品型錄
