Keysight J7201C衰減控制裝置DC to 26.5 GHz, 0 to 101 dB, 1 dB step

推薦使用使用頻率可從直流到26.5GHz的J7201C衰減器，0 至 101 dB 衰減，步長為 1 dB。專為研發和製造測試中的無線通信以及航空航天和國防應用而設計。

Keysight J7201C主要技術規格

Attenuator Control Capability

- Attenuation sweep function – define the sweep time, number of cycles and step size for your application
- Relative attenuation step function - set attenuation relative to any value
- Attenuation steps - 0 dB to 101 dB, 101 dB to 0 dB, or back and forth for the preset number of cycles (1 to 1000)
- User selectable sweep time - 50 ms to 10 s; 50 ms incremental

Specifications

- 0.03 dB insertion loss repeatability typical per section for the entire 5 million cycles
- Excellent attenuation accuracy and flatness

Remote Control and Programming

- LXI Class C compliant for easy remote integration

* 延伸閱讀：查看其他衰減器
* 延伸閱讀：查看其他微波測試配件

主要規格
訂購資訊

An integrated attenuation solution for wireless communication

J7201C attenuation control units provide an integrated solution for R&D and manufacturing engineers in wireless communication, aerospace and defense and electronic component industries. Operating from DC to 26.5 GHz, the J7201C provides attenuation up to 101 dB with a 1 dB step size. A unique attenuation sweep function lets you select start/stop attenuation, step size, dwell time and number of cycles of for your application. J7201C offers exceptional < 0.03 dB insertion loss repeatability typical per section for the entire 5 million cycles which reduces your cost of ownership.

Designed in a compact half-rack, 2 unit high form factor, the Keysight J7201C ensures ease-of-use in benchtop applications and greater efficiency and throughput in ATE testing. GPIB, USB and LAN connectivity (LXI Class C Compliant) allow easy remote control and triggering.

Typical applications

J7201C attenuation control unit's attenuation sweep function makes it ideal for wireless communication and aerospace and defense applications.
