對歐盟客戶的通知：此產品未達到 EU RoHS directive 2011/65/EU 標準，因此是德科技不再向歐盟成員國銷售此產品。在全球支援期限結束之前，是德科技仍將繼續提供服務與支援。
* 延伸閱讀：USB/LAN power sensor & meter 介紹
* 延伸閱讀：查看其他功率感測器
* 延伸閱讀：查看網路分析儀
* 延伸閱讀：查看頻譜分析儀
* 延伸閱讀：查看信號產生器
| 通道 | 1 |
| 連接器類型: | Several connector types are available, power sensors dependent |
| 頻率範圍: | • N8480 Sensors 100kHz to 50 GHz |
| • 8480 Sensors 10 MHz to 50 GHz | |
| • Q/R/V/W8486A Sensors 26.5 GHz to 110 GHz | |
| • E441XA CW Sensors 10 MHz to 33 GHz | |
| • E9300 Sensors 9 kHz to 24 GHz | |
| • E9320 Sensors 50 MHz to 18 GHz | |
| 速度: | up to 1000 readings/sec |
| 相容的功率感測器 / 功率錶: | • 8480 Series |
| • E4410A Series | |
| • E9300 Series | |
| • E9320 Series | |
| 產品特色: | measure peak, average and time-gated power |
| 功率範圍: | • N8480 Sensors -70 dBm to +44 dBm |
| • 8480 Sensors -70 dBm to +44 dBm | |
| • Q/R/V/W8486A Sensors -30 dBm to +20 dBm | |
| • E441XA CW Sensors -70 dBm to +20 dBm | |
| • E9300 Sensors -60 dBm to +44 dBm | |
| • E9320 Sensors -65 dBm to +20 dBm |
找不到您想要的配件嗎？請嘗試點擊特殊選項進行查找。
| E4416A-002 | Parallel rear panel sensor input connector and front panel reference calibrator connector |
| E4416A-003 | Parallel rear panel sensor input connector and rear panel reference calibrator connector |
| E4416A-004 | Delete power sensor cable |
| E4416A-005 | Include power sensor cable, E9288A length 5-ft (1.5m) |
| E4416A-006 | Include power sensor cable, E9288B length 10-ft (3m) |
| E4416A-0B1 | English language user and installation guide; printed |
| E4416A-0B3 | English language service manual, printed |
| E4416A-0BF | English language programming guide |
| E4416A-0BK | English language user and programming guide, printed |
| E4416A-1A7 | Calibration + Uncertainties + Guardbanding (Not Accredited) |
| E4416A-908 | Rackmount kit (one instrument) |
| E4416A-909 | Rackmount kit (two instruments) |
| E4416A-A6J | ANSI Z540-1-1994 Calibration |
| E4416A-ABJ | Japan - Japanese user guide and English programming guide, printed |
| E4416A-CD1 | Documentation Optical Disk |
| E4416A-E20 | Bundled with transit case and E9322A sensor |
| E4416A-E23 | Bundled with carrying case and E9322A sensor |
| 1CM007A | Rackmount Flange Kit 88.1mm H (2U) - Brackets, Lock Link for Side-by-Side Mount |
| 34131A | Transit case for half-rack 2U high instruments (e.g., 34401A) |
| 34141A | Yellow soft carry/operating case |
| 34161A | Accessory pouch for 34401A, 33120/250A, 34970A, 53131A, etc. |
| E9288A | Sensor cable 1.5m/5ft (E9288A) |
| E9288B | Sensor cable 3m/10ft (E9288B) |
| E9288C | Sensor cable 10m/31ft (E9288C) |
