TDR Cal./Validation Substrate
產品詳細介紹

主要用於:TDR Cal./Validation Substrate

  • *主要規格:

    Electrical Specifications
    Substrate: ceramic
    Impedance: Short, through, 50 Ω, 85 Ω, 100 Ω and 50 Ω differential mode standard
    Contact Material: Hard gold
    Accuracy: < 0.15%

    Mechanical Specifications
    Width: 25.4 mm/1.0 in
    Height: 19.1 mm/0.75 in
    Thickness: 0.6 mm/0.025 in
    Pitch Spacing: 1 mm/0.8 mm/0.6 mm/0.4 mm

    *產品特性:

    High Bandwidth: Up to 18 GHz
    High Repeatability: No moving parts
    Ruggedized: Strong enough for hand probing
    Low Cost: Fractional cost of compatible probes
